Unique trigger design, very comfortable operation sense.
Fast and accurate in reading all 1D codes.
Super scanning and decoding ability, can read incomplete and fuzzy codes.
The service life of the button reaches up to 5 million times.
Supporting keyboards of over 20 countries and regions.
Full quakeproof, waterproof, dustproof, anti-knock design and EMI shielding; Suitable for each kind of industrial environment.
Model
NT-1698LY
Operating Frequency
2042MHz-2480Mhz, 1MHz Channel Spacing
Bluetooth Version
V 3.0
Color Depth:
32Bit
Supported Symbologies
Code 39, Full ASCII, Code bar, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, Code 93, Code 128, Code 32, Standard code 39, EAN 128, MSI, EAN 8 & 13, UPCA&E, Plessey, Databar14, TELEPE
Operationtd>
Manual / Automatic
Optical Resolution:
4 mil
Precision
≥ 4 mil (0.10mm)/s
Decode speed
120 times/second
Decode error rate
Less than 1/8 million/td>
Depth of scan field
10-800mm
Print Contrast Signal
≥ 30°
Scan angle
Yaw(Skew)45° & Pitch60°
Working Distance
Over 10meter
Cradle (optional)
Stainless Steel, 360° Adjustable
Safety
Full quakeproof, waterproof, dustproof, antiknock-design and EMI shielding
Mechanical/Electrical
Working Voltage
3.3V
Working Current
Receiving 26.6mA, Launching 24mA
Scanner Material
Eco-friendly, ABS+Rubber
Environment
Operating temperature
-20°C-45°C
Storage temperature
-20°C-45°C
Humidity
5%-85%
Warranty Period : 3 Months **All power cord and adapter comes with 1 Month warranty from installation date. ** Warranty does not cover wear and tear, damages arisen from misuse or use not in accordance with product instructions.
